■ Used for the appearance detection of modules after welding, as well as the location of the bus bar and the edge green distance detection.
■ Three bus bars can be detected simultaneously.
■ Can customize the back appearance inspection, bus bar welding inspection, laminated A appearance inspection (back appearance + bus bar welding).
Detection principle:
Welding inspection of busbar
The long side feed is completed by matching three 4K line scan cameras with upper and lower backlights
Back appearance inspection
The short side feed is completed with an 8K line scan camera and an upper and lower line light source
Product specifications:
